Datasheets V0
| Models |
IN |
OUT |
M.O.Q. |
Orifice |
Working pressure |
Back- pressure |
Room temperature |
Fluid temperature |
|
V0
|
1/8" M
|
PG 5 mm
|
108
|
2 mm
|
0 - 5 bar
|
5 bar
|
60° C
|
140° C
|
Technical data sheets V2
| Modell |
IN |
OUT |
M.O.Q. |
Orifice |
Working pressure |
Back- pressure |
Room temperature |
Fluid temperature |
|
V2 - 1.5 mm
|
PF 4 mm
|
PF 4 mm
|
108
|
1.5 mm
|
0 - 18 bar
|
8 bar
|
60° C
|
140° C
|
|
V2 - 1.5 Mmm
|
Fork
|
PF 4 mm
|
108
|
1.5 mm
|
0 - 18 bar
|
8 bar
|
60° C
|
140° C
|
|
V2 - 2.0 mm
|
Fork
|
Fork
|
108
|
2 mm
|
0 - 15 bar
|
8 bar
|
60° C
|
140° C
|
|
V2 - 2.0 mm
|
Fork
|
PF 4 mm
|
108
|
2 mm
|
0 - 15 bar
|
8 bar
|
60° C
|
140° C
|
|
V2 - 2.5 mm
|
PF 6 mm
|
PF 6 mm
|
108
|
2,5 mm
|
0÷12bar (24DC) / 0÷7bar (230 & 220-240)V
|
8 bar
|
60° C
|
140° C
|
|
V2 - 2.5 mm
|
Fork
|
Fork
|
108
|
2,5 mm
|
0÷12bar (24DC) / 0÷7bar (230 & 220-240)V
|
8 bar
|
60° C
|
140° C
|
Datasheets V2 Normally open
| Model |
IN |
OUT |
M.O.Q. |
Orifice |
Working pressure |
Back-pressure |
Room temperature |
Fluid temperature |
|
V2 - 2.0 mm NO
|
Fork
|
Fork
|
108
|
DN 2
|
5 bar
|
18 bar
|
0 - 60°C
|
0 - 140°C
|
|
V2 - 2.0 mm NO
|
PF 4
|
PF 4
|
108
|
DN 2
|
5 bar
|
18 bar
|
0 - 60°C
|
0 - 140°C
|
|
V2 - 2.0 mm NO
|
PF 6
|
PF 6
|
108
|
DN 2
|
5 bar
|
18 bar
|
0 - 60°C
|
0 - 140°C
|
|
V2 - 2.0 mm NO
|
Fork
|
PF 4
|
108
|
DN 2
|
5 bar
|
18 bar
|
0 - 60°C
|
0 - 140°C
|
Table Power and Consuption
| Progress code |
Voltage |
Frequency |
Holding power |
In rush power |
Consuption holding current |
Consuption in rush current |
cos |
ED duty cycle |
Approvals |
|
1
|
24 V DC
|
=
|
11,8 W
|
/
|
491 mA
|
/
|
/
|
3ON 5OFF
|
ENEC, GW
|
|
2
|
24 V DC
|
=
|
11,8 W
|
/
|
491 mA
|
/
|
/
|
3ON 5OFF
|
ENEC, UL
|
|
3
|
230 V AC
|
50/60 HZ
|
11.1 VA
|
/
|
/
|
/
|
/
|
3ON 5OFF
|
|
|
4
|
12V DC
|
=
|
16,8 W
|
/
|
1400 mA
|
/
|
/
|
3ON 5OFF
|
ENEC, GW
|
